Products Description
The Smart AC EV Charger Wallbox is designed for convenient home, garage and parking-area EV charging. Power configurations include 3.3kW, 3.5kW, 7kW, 7.2kW, 11kW and 22kW, with adjustable charging current from 6A to 32A depending on the selected configuration.
Available with J1772 Type 1 or Mennekes Type 2 charging connectors, this wall mounted EV charger combines plug-and-charge operation with optional smart functions including RFID access, App control, WiFi, optional 4G and OCPP 1.6/2.0 connectivity.
Smart AC EV Charger Wallbox for Home Charging
The AC EV charger wallbox is a wall-mounted Mode 3 charging solution for electric vehicles at homes, garages and parking areas. Available power configurations range from 3.3kW to 22kW, with Type 1 or Type 2 connector options, adjustable current and multiple charging control methods.
Designed with a compact enclosure measuring approximately32 × 25 × 6 cm, the charger occupies limited wall space and is suitable for indoor or outdoor EV charging installations.
Users can select the configuration according to the available electrical supply and vehicle charging capability. This makes the smart EV charger suitable for both single-phase and three-phase charging applications.
7kW 11kW 22kW AC EV Charger Wallbox Power Options
The AC EV charger wallbox is available in 3.3kW, 3.5kW, 7kW, 7.2kW, 11kW and 22kW configurations. Current settings include 6A, 8A, 10A, 13A, 16A, 24A and 32A, allowing different charger versions to match compatible vehicles and available electrical supplies.
| Available Output Power | 3.3kW / 3.5kW / 7kW / 7.2kW / 11kW / 22kW |
|---|---|
| Adjustable Current | 6A / 8A / 10A / 13A / 16A / 24A / 32A |
| Nominal Input | 220V / 380V |
| Single Phase Input Range | 110V–250V |
| Three Phase Input Range | 110V–450V |
| Frequency | 50Hz / 60Hz |
| Output | AC |
The actual charging power is determined by the selected charger configuration, electrical supply and the vehicle's onboard AC charging capability. The electrical circuit should therefore be matched to the charger by a qualified installer.
Type 1 and Type 2 Smart EV Charger Connector Options
The smart EV charger can be configured with a J1772 Type 1 connector or a Mennekes Type 2 connector. The Type 2 version uses an IEC 62196-2 charging plug. Connector selection should match the vehicle charging inlet and the charging standard used in the target market.
| Connector Option | Specification |
|---|---|
| Type 1 | J1772 Type 1 |
| Type 2 | Mennekes Type 2 / IEC 62196-2 |
| Charging Mode | Mode 3 |
| Connection | Case C |
This connector flexibility allows one wallbox platform to be configured for different regional markets without assuming that every electric vehicle uses the same AC charging inlet.
WiFi App Controlled EV Charger with Optional 4G
The App controlled EV charger supports WiFi connectivity and optional 4G for connected charging applications. App control provides a smart operating option where network access is available, while RFID and plug-and-charge configurations allow the wallbox to serve locations with different access and connectivity requirements.
For private homes and garages where simple access is preferred,plug and charge provides a straightforward charging method. The vehicle can be connected to the charger without requiring a network-based starting method.
For connected installations, the smart wallbox can be configured for App-based operation through an available WiFi connection or optional 4G communication.
RFID EV Charger for Controlled Parking Areas
The RFID EV charger provides card-based charging access for locations where charging authorization is required. RFID control is particularly useful for garages, residential parking and underground parking areas, including locations where WiFi or mobile network coverage may be limited or unavailable.
RFID provides a practical alternative to App control when internet connectivity is unreliable. An authorized RFID card can be used as the local access method for the charging station.
This allows the same AC EV charger wallbox platform to be adapted for private charging as well as controlled-access parking installations.
OCPP 1.6 and OCPP 2.0 Smart EV Charger
The OCPP EV charger is specified with support for OCPP 1.6 and OCPP 2.0. Combined with WiFi and optional 4G connectivity, OCPP capability makes the smart wallbox suitable for charging applications that require communication between compatible charging hardware and a supported charging management platform.
OCPP functionality is particularly relevant to networked EV charging projects. Before deployment, buyers should confirm compatibility between the selected charger configuration, firmware and the intended OCPP backend or charging management system.
5m Type 2 EV Charger Cable with Custom Length Options
The Type 2 EV charger is supplied with a standard 5-meter charging cable, while 7.5-meter, 10-meter and customized cable lengths are available. Different cable lengths help accommodate variations in parking layout, wallbox position and vehicle charging-port location without changing the core charger platform.
The charging cable uses materials specified according to RoHS requirements and is designed for regular charging use. Cable color can also be customized for different project or product requirements.
When choosing cable length, the installation position and expected vehicle parking direction should be considered to provide sufficient charging reach.
Compact Wall Mounted EV Charger for Indoor and Outdoor Use
The wall mounted EV charger measures approximately 32 × 25 × 6 cm, around the footprint of an A4-size sheet. Its compact wallbox design is intended for indoor and outdoor charging applications, including private houses, garages, residential parking areas and compatible commercial parking installations.
The enclosure combines tempered glass and thermoplastic material. The specified insulating material has a UL94 V-0 flammability classification.
| Mechanical Dimension | 32 × 25 × 6 cm |
|---|---|
| 7kW Weight | < 7.5 kg |
| 11kW Weight | < 7.5 kg |
| 22kW Weight | < 8 kg |
| Enclosure | Tempered Glass + Thermoplastic |
| Insulator Flammability | UL94 V-0 |
| Application | Indoor / Outdoor |
AC EV Charger Wallbox Technical Specifications
The AC EV charger wallbox combines 3.3kW–22kW power options, 6A–32A current settings, 50/60Hz operation, Type 1 or Type 2 connectors, Mode 3 charging, a standard 5-meter cable, WiFi, optional 4G, RFID and App control, with OCPP 1.6/2.0 connectivity options.
| Product Type | Smart AC EV Charger Wallbox |
|---|---|
| Application | Home / Garage / Parking Area |
| Output Power | 3.3kW / 3.5kW / 7kW / 7.2kW / 11kW / 22kW |
| Output Type | AC |
| Input Voltage | 220V / 380V |
| Single Phase Input Range | 110V–250V |
| Three Phase Input Range | 110V–450V |
| Current Settings | 6A / 8A / 10A / 13A / 16A / 24A / 32A |
| Frequency | 50Hz / 60Hz |
| Connector Options | J1772 Type 1 / Mennekes Type 2 |
| Type 2 Standard | IEC 62196-2 |
| Charging Mode | Mode 3 |
| Connection | Case C |
| Network | WiFi / 4G Optional |
| Smart Control | App / RFID / Plug and Charge |
| OCPP | 1.6 / 2.0 |
| Standard Cable | 5 m |
| Optional Cable Length | 7.5 m / 10 m / Customized |
| Dimension | 32 × 25 × 6 cm |
| Certification | CE / RoHS / TÜV |
| Condition | New |
Home EV Charger for House, Garage and Parking Installation
The home EV charger is designed for wall-mounted charging in private houses, garages and parking areas. Plug-and-charge operation suits simple private installations, RFID supports controlled-access locations, and App connectivity can be selected for charging environments with WiFi or optional 4G network access.
Private House
For private residential charging, plug-and-charge operation provides a simple way to connect a compatible EV when the vehicle is parked at home.
Garage
The compact 32 × 25 × 6 cm wallbox can be installed in compatible garage locations while keeping the charging equipment mounted away from the parking floor.
Underground Parking
RFID control can be useful in underground parking areas requiring access control, particularly where mobile or WiFi network coverage is limited.
Connected Parking Area
Where WiFi or optional 4G connectivity is available, App and OCPP functions can be selected according to the charging project requirements.
Smart AC EV Charger Wallbox FAQ
Buyers selecting a smart AC EV charger wallbox should compare charging power, available current, single-phase or three-phase supply, vehicle connector, cable length and control method. This platform offers 3.3kW–22kW versions, Type 1/Type 2 options, adjustable current, RFID, App, WiFi and optional 4G connectivity.
What power options are available?
Available configurations include 3.3kW, 3.5kW, 7kW, 7.2kW, 11kW and 22kW.
Can the charging current be adjusted?
The specified current settings include 6A, 8A, 10A, 13A, 16A, 24A and 32A. Available settings depend on the selected charger configuration.
Does this EV charger support Type 2 vehicles?
A Mennekes Type 2 version with an IEC 62196-2 connector is available. Compatibility should be confirmed against the vehicle's AC charging inlet before ordering.
Is a Type 1 EV charger available?
Yes. A J1772 Type 1 connector configuration is also specified for markets and compatible vehicles requiring Type 1 AC charging.
Does the wallbox support single-phase and three-phase power?
The supplied specifications list single-phase input from 110V to 250V and three-phase input from 110V to 450V. The selected charger version and local electrical supply must be matched correctly.
Does the EV charger support App control?
Yes. App control is available for connected charging applications using supported WiFi or optional 4G connectivity.
Can RFID be used without WiFi?
RFID is intended as a local access-control option and can be useful in locations such as underground parking where WiFi or mobile coverage is limited.
Does the charger support OCPP?
The supplied product specifications list OCPP 1.6 and OCPP 2.0 support. Compatibility with the intended charging management platform should be confirmed before deployment.
What is the standard charging cable length?
The standard cable length is 5 meters. 7.5-meter, 10-meter and customized cable lengths are also available.
Can this wallbox be installed outdoors?
The supplied product information lists both indoor and outdoor applications. The final installation should follow the selected product configuration, local electrical requirements and installation instructions.
