Welcome to the SCYUNCHENG Technical Support Center. This comprehensive manual covers the installation, electrical specifications, nozzle calibration, and troubleshooting procedures for our CNG and LPG Sequential Injector Rails (available in 2Ω and 3Ω resistance options for 3-cylinder and 4-cylinder engines).
1. Technical Specifications & Setup
Proper mechanical placement and electrical matching are crucial for stable gas flow and precise fuel delivery in converted petrol vehicles:
Working Pressure: Designed for an optimal operating pressure range of 0.5 to 2.5 bar.
Coil Resistance: Standard options include 2 Ohm and 3 Ohm configurations to match various ECU outputs.
Mounting Position: Injector rails should be mounted as close as possible to the intake manifold with short, equal-length injection hoses.
2. Step-by-Step Installation Guidelines
Nozzle Sizing & Drilling: Select the correct intake manifold nozzle diameter based on engine horsepower per cylinder. Drill and tap the manifold at a shallow angle facing the intake valves.
Hose Connection: Connect the high-pressure gas hoses securely from the injector outlets to the manifold nozzles using spring clamps to prevent vacuum leaks.
Electrical Harness: Plug the 2-pin connector from the ECU wiring harness firmly into each injector coil, ensuring secure locking clips.
3. Download Technical Documentation
Access and download our official installation sheets and reference diagrams below:
📄 CNG/LPG Injector Rail Installation & Maintenance Manual (PDF)
CNG LPG Injector Rail Installation & Maintenance Manual .pdf
